Kelvin probe force microscopy work function characterization of transition metal oxide crystals under ongoing reduction and oxidation

Controlling the work function of transition metal oxides is of key importance with regard to future energy production and storage. As the majority of applications involve the use of heterostructures, the most suitable characterization technique is Kelvin probe force microscopy (KPFM), which provides excellent energetic and lateral resolution.*

In their study “Kelvin probe force microscopy work function characterization of transition metal oxide crystals under ongoing reduction and oxidation» Dominik Wrana, Karol Cieślik, Wojciech Belza, Christian Rodenbücher, Krzysztof Szot and Franciszek Krok present the advantages and limitations of the FM-KPFM technique using the example of a newly discovered TiO/SrTiO3(100) (metal/insulator) heterostructure, which has potentially high technological relevance.*

In the same article a combined conductivity and work function study from the same surface area is presented, showing the possibility of obtaining full information on the electronic properties when the KPFM technique is accompanied by local conductivity atomic force microscopy (LC-AFM).*

The authos present the measurement of the crystalline TiO work function and its dependence on the gaseous pressure of air using Kelvin probe force microscopy.

In order to ensure reproducible FM-KPFM results, two different types of AFM cantilevers were used: NANOSENSORS™ PointProbe® Plus PPP-ContPt (PtIr-coated) and NANOSENSORS™ Platinum Silicide PtSi-FM.*

Such cantilevers are widely used as conducting tips in a contact mode AFM, allowing for a high lateral resolution in conductivity measurements. The remarkable mechanical stability of the selected cantilevers allowed for the noncontact mode measurements (with a Kelvin loop) using the very same tip, maintaining oscillations at the higher harmonics of the fundamental frequency (≈75 kHz). Hence, in order to record current and CPD maps from the very same sample area, KPFM measurements were first performed with the soft cantilever forced to oscillate at higher harmonics, then the tip was retracted tens of nanometers from the surface, all feedback loops were turned down and a contact mode AFM scan was performed when approached with a single loop maintaining a deflection set point of 10–30 mV. The high conductivity of both TiO and STO materials enabled a low sample bias of +1 mV for the LC-AFM measurements to be used.*

Figure 4 from “Kelvin probe force microscopy work function characterization of transition metal oxide crystals under ongoing reduction and oxidation”: KPFM lateral resolution on high TiO/STO structures. a) Topography and b) work function of TiO nanowire array on SrTiO3(100). c) Height (black line) and work function (green line) profiles of two adjacent TiO nanowires, showing high KPFM contrast. d) Dependence of the CPD resolution (estimated as ΔCPD/CPD, see c) on the separation between TiO nanowires, with A + B/X asymptote fit. Insets show the SEM images of the actual PtSi cantilever used in the experiments with a tip radius of 15 nm.

*Dominik Wrana, Karol Cieślik, Wojciech Belza, Christian Rodenbücher, Krzysztof Szot, Franciszek Krok
Kelvin probe force microscopy work function characterization of transition metal oxide crystals under ongoing reduction and oxidation
Beilstein Journal of Nanotechnology 2019, 10, 1596–1607
DOI: 10.3762/bjnano.10.155

Please follow this external link to read the full article: https://www.beilstein-journals.org/bjnano/articles/10/155

Open Access The article “Kelvin probe force microscopy work function characterization of transition metal oxide crystals under ongoing reduction and oxidation” by Dominik Wrana, Karol Cieślik, Wojciech Belza, Christian Rodenbücher, Krzysztof Szot and Franciszek Krok is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons license, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons license and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this license, visit http://creativecommons.org/licenses/by/4.0/.

On-chip integration of single solid-state quantum emitters with a SiO2 photonic platform

One important building block for future integrated nanophotonic devices is the scalable on-chip interfacing of single photon emitters and quantum memories with single optical modes.*

In the article “On-chip integration of single solid-state quantum emitters with a SiO2 photonic platform” Florian Böhm, Niko Nikolay, Christoph Pyrlik, Jan Schlegel, Andreas Thies, Andreas Wicht,Günther Tränkle and Oliver Benson present the deterministic integration of a single solid-state qubit, the nitrogen-vacancy (NV) center, with a photonic platform consisting exclusively of SiO2grown thermally on a Si substrate.*
The platform stands out by its ultra-low fluorescence and the ability to produce various passive structures such as high-Q micro resonators and mode-size converters. By numerical analysis an optimal structure for the efficient coupling of a dipole emitter to the guided mode could be determined. Experimentally, the integration of a preselected NV emitter was performed with an atomic force microscope and the on-chip excitation of the quantum emitter as well as the coupling of single photons to the guided mode of the integrated structure could be demonstrated. The authors approach shows the potential of this platform as a robust nanoscale interface of on-chip photonic structures with solid-state qubits.*

After optically verifying the successful placement of the nanodiamond hosting a single nitrogen-vacancy ( NV ) center by performing a confocal scan, the article describes how the nanoparticle is pushed to the inner edge of the rib waveguide in a subsequent step, using a NANOSENSORS™ AdvancedTEC™ ATEC-NC tip-view AFM probe.*


Figure 1 a from: “On-chip integration of single solid-state quantum emitters with aSiO2photonic platform” by Florian Böhm et al:
Waveguide design and functionalization
(a) Illustration of the SiO2waveguide structure and the field profile(E2∣∣)of the guided TM fundamental optical mode at 700 nm. Also the deterministic positioning process of the diamond-nanocrystal containing a single NV center (the NV crystal structure is shown in the inset) into the inner edge of the integrated SiO2rib waveguide with an atomic force microscope (AFM) tip, is shown.

*Florian Böhm, Niko Nikolay, Christoph Pyrlik, Jan Schlegel, Andreas Thies, Andreas Wicht,Günther Tränkle and Oliver Benson
On-chip integration of single solid-state quantum emitters with a SiO2 photonic platform
New Journal of Physics 21 (2019 ) 045007
DOI: https://iopscience.iop.org/article/10.1088/1367-2630/ab1144

Please follow this external link to read the full article: https://iopscience.iop.org/article/10.1088/1367-2630/ab1144/pdf

Open Access: The article “On-chip integration of single solid-state quantum emitters with a SiO2 photonic platform” by Florian Böhm, Niko Nikolay, Christoph Pyrlik, Jan Schlegel, Andreas Thies, Andreas Wicht, Günther Tränkle and Oliver Benson is licensed under a Creative Commons Attribution 3.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons license, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons license and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this license, visit http://creativecommons.org/licenses/by/3.0/.
