Substrate properties modulate cell membrane roughness by way of actin filaments

“Cell membrane roughness has been proposed as a sensitive feature to reflect cellular physiological conditions”*
In the article “Substrate properties modulate cell membrane roughness by way of actin filaments” Chao-Hung Chang, Hsiao-Hui Lee, and Chau-Hwang Lee employed the non-interferometric wide-field optical profilometry (NIWOP) technique to measure the membrane roughness of living mouse embryonic fibroblasts with different conditions of the culture substrate to find out whether membrane roughness is associated with the substrate properties. By controlling the surface density of fibronectin (FN) coated on the substrate, they found that cells exhibited higher membrane roughness as the FN density increased in company with larger focal adhesion (FA) sizes.

The examination of membrane roughness was also confirmed with atomic force microscopy.
The long cantilever of NANOSENSORS uniqprobe qp-SCONT AFM probes ( 125-μm long, spring constant 0.01 N/m.) was used to observe the membrane topography on living MEFs.

If you would like to learn more about the NANOSENSORS uniqprobe AFM probes series which offers soft, drift-reduced AFM probes with unsurpassed small variation in spring constant and resonance frequency mainly for biology and life science applications but also for other aplications such as high speed scanning then please have a look at our recently updated Uniqprobe brochure: https://www.nanosensors.com/pdf/NANOSENSORS-uniqprobe-brochure.pdf .

Supplementary Figure S1 from Chao-Hung Chang et al. “Substrate properties modulate cell membrane roughness by way of actin filaments”: Images of membrane topography determined by atomic force microscopy (AFM). MEFs were seeded on the polymer coverslip-bottom μ-dishes coated with 0 or 10 μg/ml FN for 6 hours for the measurement of membrane roughness by AFM. The regions marked by the white squares in the bright-field images are displayed in the membrane topography. Scale bar, 10 μm. NANOSENSORS uniqprobe qp-SCONT AFM probes(long cantilever length 125 um, spring constant 0.01 N/m) were used.
Supplementary Figure S1 from Chao-Hung Chang et al. “Substrate properties modulate cell membrane roughness by way of actin filaments”: Images of membrane topography determined by atomic force microscopy (AFM). MEFs were seeded on the polymer coverslip-bottom μ-dishes coated with 0 or 10 μg/ml FN for 6 hours for the measurement of membrane roughness by AFM. The regions marked by the white squares in the bright-field images are displayed in the membrane topography. Scale bar, 10 μm.

*Chao-Hung Chang, Hsiao-Hui Lee, Chau-Hwang Lee
Substrate properties modulate cell membrane roughness by way of actin filaments
Nature Scientific Reports, volume 7, Article number: 9068 (2017)
DOI: https://doi.org/10.1038/s41598-017-09618-y

Please follow this external link for the full article: https://rdcu.be/bdZm9

Open Access The article “Substrate properties modulate cell membrane roughness by way of actin filaments” by  Chao-Hung Chang et al. is licensed under a Creative Commons Attribution 4.0 International License, which permits use, sharing, adaptation, distribution and reproduction in any medium or format, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made. The images or other third party material in this article are included in the article’s Creative Commons license, unless indicated otherwise in a credit line to the material. If material is not included in the article’s Creative Commons license and your intended use is not permitted by statutory regulation or exceeds the permitted use, you will need to obtain permission directly from the copyright holder. To view a copy of this license, visit http://creativecommons.org/licenses/by/4.0/.

Get free NANOSENSORS qp-fast AFM probes at booth 610 at MRS Fall 2018

Are you looking for AFM probes with unsurpassed small variation in spring constant and resonance frequency? Then visit the NanoAndMore USA booth no. 610 at the 2018 MRS Fall Exhibit and get your free sample of NANOSENSORS™ uniqprobe qp-fast AFM probes.

NANOSENSORS uniqprobe qp-fast AFM probe
NANOSENSORS uniqprobe qp-fast AFM probe











A fibrin biofilm covers blood clots and protects from microbial invasion

New interesting publication by Macrea et. al mentioning the use of NANOSENSORS uniqprobe qp-BioAC:

“Hemostasis requires conversion of fibrinogen to fibrin fibers that generate a characteristic network, interact with blood cells, and initiate tissue repair. The fibrin network is porous and highly permeable, but the spatial arrangement of the external clot face is unknown. Here we show that fibrin transitioned to the blood-air interface through Langmuir film formation, producing a protective film confining clots in human and mouse models. We demonstrated that only fibrin is required for formation of the film, and that it occurred in vitro and in vivo. The fibrin film connected to the underlying clot network through tethering fibers. It was digested by plasmin, and formation of the film was prevented with surfactants. Functionally, the film retained blood cells and protected against penetration by bacterial pathogens in a murine model of dermal infection. Our data show a remarkable aspect of blood clotting in which fibrin forms a protective film covering the external surface of the clot, defending the organism against microbial invasion.”*

The AFM imaging and force measurements mentioned in this article were performed using CB3 of the NANOSENSORS™ uniqprobe qp-BioAC.

Supplemental Figure. 6. From Macrea et. al “A fibrin biofilm covers blood clots and protects from microbial invasion” Mechanisms and roles of fibrin film. A, Sneddon model used to calculate Young’s Modulus, where F is the force from the force curve, E is Young’s modulus, ν is Poisson’s ratio (0.5), α is the half angle for the indenter (15 degrees for our tips), and δ is the indentation. Note that this equation is only accurate with a half angle of 15 degrees for the first 200nm of indentation. B, Strength of the fibrin film in clots produced with plasma and thrombin with or without T101 (FXIII inhibitor ) investigated using atomic force microscopy (AFM). Fibrin fibres were visible under the film surface and these areas presented with stiffer Young’s modulus than fibrin film suspended between fibres. Grey lines in the zoomed-in images represent Young’s modulus scan area represented in the line force graphs. Scale bar - 2μm. C, Young’s Modulus was calculated for the suspended film and the film supported by fibers with and without T101 by fitting a Sneddon model to all AFM force curves found over the entire area that was imaged. 20 measurements were taken for each condition. **** P<0.0001. D, Clots produced from plasma with thrombin, under a layer of oil or enclosed in a ball of petroleum jelly, to eliminate the air - liquid interface, imaged by LSCM. Solid and dotted yellow lines indicate location of air liquid interface, n=3 experiments. Scale bars - 50μm. NANOSENSORS qp-BioAC AFM probes (CB3 ) were used for the AFM imaging and force measurements.
Supplemental Figure. 6. From Macrea et. al “A fibrin biofilm covers blood clots and protects from microbial invasion Mechanisms and roles of fibrin film. A, Sneddon model used to calculate Young’s Modulus, where F is the force from the force curve, E is Young’s modulus, ν is Poisson’s ratio (0.5), α is the half angle for the indenter (15 degrees for our tips), and δ is the indentation. Note that this equation is only accurate with a half angle of 15 degrees for the first 200nm of indentation. B, Strength of the fibrin film in clots produced with plasma and thrombin with or without T101 (FXIII inhibitor ) investigated using atomic force microscopy (AFM). Fibrin fibres were visible under the film surface and these areas presented with stiffer Young’s modulus than fibrin film suspended between fibres. Grey lines in the zoomed-in images represent Young’s modulus scan area represented in the line force graphs. Scale bar – 2μm. C, Young’s Modulus was calculated for the suspended film and the film supported by fibers with and without T101 by fitting a Sneddon model to all AFM force curves found over the entire area that was imaged. 20 measurements were taken for each condition. **** P<0.0001. D, Clots produced from plasma with thrombin, under a layer of oil or enclosed in a ball of petroleum jelly, to eliminate the air – liquid interface, imaged by LSCM. Solid and dotted yellow lines indicate location of air liquid interface, n=3 experiments. Scale bars – 50μm.

*Fraser L. Macrae, Cédric Duval, Praveen Papareddy, Stephen R. Baker, Nadira Yuldasheva, Katherine J. Kearney, Helen R. McPherson, Nathan Asquith, Joke Konings, Alessandro Casini, Jay L. Degen, Simon D. Connell,  Helen Philippou, Alisa S. Wolberg, Heiko Herwald, Robert A.S. Ariëns
A fibrin biofilm covers blood clots and protects from microbial invasion
Journal of  Clinical Investigation. 2018;128(8):3356-3368
DOI: https://doi.org/10.1172/JCI98734

Please follow this external link for the full article: https://www.jci.org/articles/view/98734#sd

The article “A fibrin biofilm covers blood clots and protects from microbial invasion” by Fraser L. Macrae et. al is licensed under the Creative Commons Attribution 4.0 International License. To view a copy of this license, visit http://creativecommons.org/ licenses/by/4.0/.
